Pair of dome tweeters, 60 W, 4 Ω | DT-284

58,00 €
Dostupnosť: Skladom
SKU
4007754171068
The Tweeter for Perfect Car Hi-fi Applications:
DT-284 “The Dome”. This tweeter provides everything expected from a top class tweeter: a sensationally linear frequency response, high level reserves, low crossover frequency, compact size and a distinct and appealing design!
Pair of dome tweeters, 60 W, 4 Ω
  • 28 mm silk cone
  • Aluminium voice coil
  • Neodymium magnet
  • High-quality ABS housing with 8-hole screw connection
  • Perfect sound of extra low distortion
  • Highest level stability
  • Exceptionally long excursion

A crossover network is required for operation! Ideal: CDN-2X


Impedance (Z): 4 Ω
Transmission method: -
Frequency range: fx-20,000 Hz
Resonant frequency (fs): 1,300 Hz
Rec. crossov. frequ. (fmax.) (12 dB/oct.): 2,000 Hz
Power rating (RMS): 60 W
Peak music power output (MAX): 100 W
Sensitivity: 91 dB/W/m
Max. rated SPL: -
Max. voltage: -
Radiation angle, horizontal: -
Radiation angle, vertical: -
Suspension compl. (Cms): -
Moving mass (Mms): -
Mech. Q factor (Qms): -
Electr. Q factor (Qes): -
Total Q factor (Qts): -
Equivalent volume (Vas): -
DC resistance (Re): -
Force factor (BxL): -
Voice coil induct. (Le): -
Voice coil diameter: Ø 28 mm
Voice coil former: -
Linear excursion (XMAX): -
Eff. cone area (Sd): -
Magnet weight: -
Magnet diameter: Ø 46 mm
Mounting cutout: Ø 50 mm
Mounting depth: 18 mm
Mounting hole diameter: -
Hole spacing X-axis: -
Hole spacing Y-axis: -
Dimensions: Ø 60 mm
Outside diameter: Ø 60 mm
Width: Ø 60 mm
Height: -
Depth: 21.70 mm
Protective class: -
Admiss. ambient temp.: 0-40 °C
Weight: 0.180 kg
Packing unit: 2
Type of speaker: -
